The motor power system and power transmission system adopt domestic advanced shock absorption technology to reduce the vibration from the power system and make the operator feel more comfortable. Equipped with a high-definition liquid crystal display device, the operator can easily understand the working status, expand the visual area, and make it more convenient and fast for the operator to view the instrument.
● The wide-view gantry allows the operator to obtain a larger field of vision, which not only improves work efficiency, but also enhances safety;
● Adjustable safety seat to make the operator feel more comfortable;
● Ultra-low anti-skid pedal Specially set anti-skid pedal.
| Model | FB30 | FB35 | |
| Characteristics | Power Type | Diesel | Diesel |
Operation type | seat | seat | |
| Rated capacity(kg) | 3000 | 3500 | |
| Load centre(mm) | 500 | 500 | |
| Lift height(mm) | 3000 | 3000 | |
| Mast Tilt Angle(Deg) | 6°/12° | 6°/12° | |
| Dimensions | Forksize(L*W*T)(mm) | 1070x125x45 | 1070x125x45 |
| Length of fork(with/without fork)（mm） | 3870/2750 | 3980/ | |
| Overall width（mm） | 1230 | 1230 | |
| Mast Extended Height(with backrest)（mm） | 4110 | 4110 | |
| Mast Lowered Height（mm） | 2050 | 2050 | |
| Overhead Guard Height（mm） | 2140 | 2140 | |
| seat height（mm） | 1000 | 1000 | |
| fork adjustment(max/min)（mm） | 1100/250 | 1100/250 | |
| Turning Radius(outside)(mm) | 2495 | 2640 | |
| Min.tinersecting aisle(mm) | 2500 | 2700 | |
| min.ground clearance(mm) | 126 | 126 | |
| front overhang(mm) | 500 | 500 | |
| rear overhang(mm) | 570 | 570 | |
| wheel base（mm） | 1770 | 1850 | |
| tread（front/rear（mm） | 1000/970 | 1000/970 | |
| Performance | Travel speed（Full/Empty load）（km/h） | 18/19 | 18/19 |
| Lifting speed（Full/Empty load）(mm/s) | 460/540 | 460/540 | |
| Lowering speed（Full/Empty load）(mm/s) | 450/420 | 450/420 | |
| Maximum traction（Full/Empty load）（KN） | 20/16 | 21/17 | |
| Max.Gradeability（%） | 20 | 20 | |
| Truck weight(unload)（kg） | 4280 | 4500 | |
| Others | Tyres,number (front/rear) | 2X/2 | 2X/2 |
| Tyre type | Polyurethane | Polyurethane | |
| Tyre dimensions | 28×9-15-12PR/6.50-10-10PR | 28×9-15-12PR/6.50-10-10PR | |
Service braking | Feet/Hydraulic | Feet/Hydraulic | |
Stopping braking | Manual/mechanical | Manual/mechanical | |
